BMS Graphics

BMS Graphics

Building Management Systems are the heart of any building. Let QA Graphics provide you with cost-effective graphics for your control system with a wide range of in-house services. This includes HVAC symbol libraries, 3D HVAC equipment, floor plans, and more. What sets QA Graphics apart is that our graphic solutions are used for any control system worldwide.

Contact Us Today

OUR SERVICES

Vector Library

V5 Library

Room Library

Floor Plans

Equipment

Scroll Down

WHAT SETS QA GRAPHICS APART?

What sets QA Graphics apart is the full range of in-house services (HVAC, BMS graphics, equipment graphics, and floor plan graphics for all control platforms) that are offered to clients worldwide. Providing customer services at an affordable cost that are quick and reliable for this highly competitive, global market.

WHY DO BUSINESS WITH QA GRAPHICS?

Whether your company has no control expertise or is an expert, you will find benefits in outsourcing your graphic needs. Our talented staff has the technical expertise needed to provide your company with the requirements to stand above the competition while allowing your control technicians to focus on core competencies.

When comparing the return on investment of outsourcing vs other traditional methods, using our services is simple, affordable, fast, and reliable.

  • AnyScreen vector colleges
  • Vector Library AHU
  • Vector Library CHWS
  • SLV5 Chiller in Platform

SYMBOL LIBRARIES

QA Graphics’ symbol libraries offer a competitive advantage in the BMS industry, delivering more appealing and realistic graphics than typically provided with BMS software. We have three libraries to offer you for a one-time fee that is compatible with more than 95% of all major mechanical systems.

  • Vector Symbol Library – scalable for mobile devices
  • SLv5 Symbol Library
  • 3D Room Library – specialized rooms that will often have multiple systems serving it

Please call us today for pricing regarding our existing Symbol Libraries.

Vector Symbol Library

View Vector Symbol Library

SLv5 Symbol Library

View BAS Symbol Library

3D Room Library

View the 3D Room Library

FEATURES OF OUR LIBRARIES

  • Represent control drawings or piping in schematic and graphical views with hundreds of symbols (animation files and static graphics)
  • *Capability to save .SVG in any size (Vector ONLY)
  • *Ability to build system graphics using scalable vector images for a mobile device or larger without pixelation or degradation of the graphics (Vector ONLY)
  • Pre-assembled damper configurations
  • Symbols for energy-efficient equipment
  • Pre-configured terminal air units
  • Datacenter graphics
  • Multiple duct lengths
  • Your 3-letter acronym on major equipment components displays a watermark on major equipment components to protect the graphics (the watermark can be visible or undetectable)

FLOOR PLAN GRAPHICS

View Floor Plans

QA Graphics offers a variety of floor plan graphics options to meet your specifications, budget, and timeline. Using existing Revit or AutoCad files, PDFs, sketches or specifications sheets, to create customized 3D and 2D floor plan graphics.

We can provide tailored plans for your company’s needs such as professional premium site plan design, BAS geared, and space planning for commercial properties. From basic to complex design, we offer high-quality floor plan graphics, quick turnaround times, and the technical expertise to include building details such as zoning, windows, built-ins, railings, furnishings, and more.

The standard turnaround time is less than 7 business days. We are able to accommodate rush deadlines with a dedicated employee to help your sales team hit your deadline.
